Height : 354 mm
Weight : 4.7 kgs (w/o battery)

■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75VA
Reservoir capacity : 120 cc

■ Crimp capacity :
Max pressure : 700 bar
Oil requires : 31 cc
Crimping force : 14.01 tons / 124.6 kN
Main application : up to 150mm² CU
