Length : 385 mm

Weight : 5.4 kgs (w/o battery)


■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75VA
Reservoir capacity : 175 cc


■ Function :
KV-45X can be applied with different functional adapters as cable cutter, sleeve & lug crimper and compatibility heads.

Max pressure : 700 bar
Max output : 14.01 tons / 124.6 kN

Ram stroke : 45 mm

※ 5 adapter heads are sold separately.
