Multifunction KA-45X

Length : 364 mm

Weight : 5.6 kgs (w/o battery)


■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75VA
Reservoir capacity : 175 cc


■ Function :
KV-45X can be applied with different functional adapters as cable cutter, sleeve & lug crimper and compatibility heads.

Max pressure : 700 bar

Max output : 14.01 tons / 124.6 kN

Ram stroke : 45 mm

※Exchangeable accessory head.

   (Heads are sold separately)

■ CP-27

    (Crimping Head Adapter)

Main Application : up to 400 mm² CU

Die Sold Separately : (CU-16 / 25 / 35 / 50 / 70 / 95 / 120 / 150 / 185 / 240 / 300 / 400)

※Accept all 12 tons die sets.

■ Hex Dies for Copper Lugs

Accepts all dies used by Alcoa, Burndy, T&B, Klauke, Cembre and Blackburn 12 ton U-type and hex-type dies. Suitable for terminals with the standard of DIN46235

■ DL-400MX

    (Die-less Hex Crimping Head Adapter)

Main Application : 10 to 400 mm² CU

Suitable for terminals with the standard of DIN46235

■ SC-45

    (Cable Cutter Head Adapter)

Cutting Capacity :

ACSR : 40 mm

Copper : 45 mm

※Cutting of piano wire is prohibited.

■ 65YC

    (Cable Cutter Head Adapter)

Cutting Capacity :

Cu Strands : 60 mm

Al Strands : 60 mm

CCP Cable : 65 mm

Underground Cable : 65 mm

(Except Armoured Cable)

※Cutting of piano wire is prohibited.
