 Detail

Length : 328 mm
Weight : 5.4 kgs (w/o battery)

■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 5 0~60Hz
Input current : 21.75 VA
Reservoir capacity : 120 cc

■ Cutting capacity :
Max pressure : 700 bar
Oil required : 32 cc
Max output : 8.78 tons / 78.1 kN
Wire rope 6x7 : 18 mm
Wire rope 6x12 : 24 mm
Wire rope 6x19 : 24 mm
Soft steel bar : 20 mm
Reinforcing rod : 16 mm
Cu strands : 24 mm
Al strands : 24 mm
ACSR : 24 mm
Guy wire 1x7 : 20 mm
Guy wire 1x19 : 20 mm

※Cutting of piano wire is prohibited.
