Detail
Height : 310 mm
Weight : 3.9 kgs (w/o battery)
■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75VA
Reservoir capacity : 120 cc
■ Crimp capacity :
Max pressure : 460 bar
Max output : 5.77 tons / 51.3 kN
Max compression : 185 mm²
Accepts BEKU type dies
Stock dies are for DIN46235 terminals
※Dies sold separately(AHE 1016/2535/5070/95120/150/185)
