Length : 329 mm
Weight : 2.8 kgs(w/o battery)
■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Reservoir capacity : 48 cc
■ Cutting capacity:
Max pressure : 550 bar
Oil required : 24 cc
Max output : 5.85 tons / 52.0 kN
Wire rope 6x7 : 16 mm
Wire rope 6x12 : 20 mm
Wire rope 6x19 : 20 mm
Soft copper bar : 20 mm
Soft aluminum bar : 16 mm
Soft steel bar : 16 mm
Reinforcing rod : 13 mm
Cu strands : 20 mm
Al strands : 20 mm
ACSR : 21 mm
Guy wire 1x7 : 15 mm
Guy wire 1x19 : 16 mm
Underground cable : 18 mm
※Cutting of piano wire is prohibited.
