Detail
Height : 380 mm
Weight : 4.1 kgs (w/o battery)
■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75 VA
Reservoir capacity : 120 cc
■ Crimp capacity :
Max pressure : 700 bar
Max output : 9.73 tons / 86.6 kN
Ram stroke : 14.5 mm
Accepts BEKU type dies
Hex. crimping : 10-240 mm²
Cu sleeves & lugs NFC 20. 130 : 10 to 240 mm²
Cu or Al bare or insulated sleeve : E54 to 230
Cu or Al sleeves & lugs DIN 48083 : KZ6 to KZ25
Pre-rounding : 35 to 240 mm²
※Dies sold separately
Accepts all dies used by Alcoa, Burndy, T&B, Klauke, Cembre and Blackburn 12 ton U-type dies.
Suitable for terminals with wall thickness little less than DIN 46235 cable lugs.
