Detail
Height : 378 mm
Weight : 4.5 kgs (w/o battery)
■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75 VA
Reservoir capacity : 120 cc
■ Crimp capacity :
U-type head
Crimping force : 12.7 tons / 125 kN
Main applications:
Cu conductors : 400 mm²
Al conductors : 240 mm²
C sleeves connector : 120 mm²
